News from the blog 2021-09-20

  • I’ve published a very simple game, Tic Tac Toe, that I created for my Python 3 Exercises for Beginners book.
  • I’ve raised back the price for my books to normal levels.
    I’ve been keeping the price to the minimum to help people that wanted to learn during covid-19. I consider that who wanted to learn has already done it.

I still have bundles with a somewhat reduced price, and I authorized LeanPub platform to do discounts up to 50% at their discretion.

Bundle of four books in https://leanpub.com/b/python3-exercises-zfs-assemble-computer

https://leanpub.com/b/python3-exercises-zfs-assemble-computer

  • I’ve been deleting AMIs, Snapshots, Volumes and backups from Amazon instances I’ll no longer use.

I’ve migrated to Docker some sites and WordPress sites and now I’m CSP (Cloud Service Provider) agnostic. I can deploy wherever I want.

We pay per GB used of storage, so my money will get a better usage.

As I said in my old article from 2013, The Cloud is for Scaling. For Startups and for Enterprises. It is too expensive for small and medium companies.

  • For those studying Python there is a Virtual Meetup about Data Analysis, in Spanish ,the 23th of September

https://www.meetup.com/tech-barcelona/events/280791310/

More meetups:

https://www.meetup.com/tech-barcelona/

Migrating some Services from Amazon to Digital Ocean

Analyzing the needs

I start with a VM, to learn about the providers and the migration project as I go.

My VM has been running in Amazon AWS for years.

It has 3.5GB of RAM and 1 Core. However is uses only 580MB of RAM. I’m paying around $85/month for this with Amazon.

I need to migrate:

  • DNS Server
  • Email
  • Web
  • Database

For the DNS Server I don’t need it anymore, each Domain provider has included DNS Service for free, so I do not longer to have my two DNS.

For the email I find myself in the same scenario, most providers offer 3 email accounts for your domain, and some alias, for free.

I’ll start the Service as Docker in the new CSP, so I will make it work in my computer first, locally, and so I can move easily in the future.

Note: exporting big images is not the idea I have to make backups.

I locate a Digital Ocean droplet with 1GB of RAM and 1 core and SSD disks for $5, for $6 I can have a NVMe version. That I choose.

Disk Space for the Statics

The first thing I do is to analyze the disk space needs of the service.

In this old AWS CentOS based image I have:

[root@ip-10-xxx-yyy-zzz ec2-user]# df -h
Filesystem      Size  Used Avail Use% Mounted on
/dev/xvda1       79G   11G   69G  14% /
devtmpfs        1.8G   12K  1.8G   1% /dev
tmpfs           1.8G     0  1.8G   0% /dev/shm

Ok, so if I keep the same I have I need 11GB.

I have plenty of space on this server so I do a zip of all the contents of the blog:

cd /var/www/wordpress
zip -r /home/ec2-user/wp_sizeZ.zip wp_siteZ

Database dump

I need a dump of the databases I want to migrate.

I check what databases are in this Server.

mysql -u root -p

mysql> show databases;

I do a dump of the databases that I want:

sudo mysqldump --password='XXXXXXXX' --databases wp_mysiteZ > wp_mysiteZ.sql

I get an error, meaning MySQL needs repair:

mysqldump: Got error: 145: Table './wp_mysiteZ/wp_visitor_maps_wo' is marked as crashed and should be repaired when using LOCK TABLES

So I launch a repair:

sudo mysqlcheck --password='XXXXXXXX' --repair --all-databases

And after the dump works.

My dump takes 88MB, not much, but I compress it with gzip.

gzip wp_mysiteZ.sql

It takes only 15MB compressed.

Do not forget the parameter –databases even if only one database is exported, otherwise the CREATE DATABASE and USE `wp_mysiteZ`; will not be added to your dump.

I will need to take some data form the mysql database, referring to the user used for accessing the blog’s database.

I always keep the CREATE USER and the GRANT permissions, if you don’t check the wp-config.php file. Note that the SQL format to create users and grant permissions may be different from a SQL version to another.

I create a file named mysql.sql with this part and I compress with gzip.

Checking PHP version

php -v
PHP 7.3.23 (cli) (built: Oct 21 2020 20:24:49) ( NTS )
Copyright (c) 1997-2018 The PHP Group
Zend Engine v3.3.23, Copyright (c) 1998-2018 Zend Technologies

WordPress is updated, and PHP is not that old.

The new Ubuntu 20.04 LTS comes with PHP 7.4. It will work:

php -v
PHP 7.4.3 (cli) (built: Jul  5 2021 15:13:35) ( NTS )
Copyright (c) The PHP Group
Zend Engine v3.4.0, Copyright (c) Zend Technologies
    with Zend OPcache v7.4.3, Copyright (c), by Zend Technologies

The Dockerfile

FROM ubuntu:20.04

MAINTAINER Carles Mateo

ARG DEBIAN_FRONTEND=noninteractive

# RUN echo "nameserver 8.8.8.8" > /etc/resolv.conf

RUN echo "Europe/Ireland" | tee /etc/timezone

# Note: You should install everything in a single line concatenated with
#       && and finalizing with
# apt autoremove && apt clean

#       In order to use the less space possible, as every command
#       is a layer

RUN apt update && apt install -y apache2 ntpdate libapache2-mod-php7.4 mysql-server php7.4-mysql php-dev libmcrypt-dev php-pear git mysql-server less zip vim mc && apt autoremove && apt clean

RUN a2enmod rewrite

RUN mkdir -p /www

# If you want to activate Debug
# RUN sed -i "s/display_errors = Off/display_errors = On/" /etc/php/7.2/apache2/php.ini
# RUN sed -i "s/error_reporting = E_ALL & ~E_DEPRECATED & ~E_STRICT/error_reporting = E_ALL/" /etc/php/7.2/apache2/php.ini
# RUN sed -i "s/display_startup_errors = Off/display_startup_errors = On/" /etc/php/7.2/apache2/php.ini
# To Debug remember to change:
# config/{production.php|preproduction.php|devel.php|docker.php}
# in order to avoid Error Reporting being set to 0.

ENV PATH_WP_MYSITEZ /var/www/wordpress/wp_mysitez/
ENV PATH_WORDPRESS_SITES /var/www/wordpress/

ENV APACHE_RUN_USER  www-data
ENV APACHE_RUN_GROUP www-data
ENV APACHE_LOG_DIR   /var/log/apache2
ENV APACHE_PID_FILE  /var/run/apache2/apache2.pid
ENV APACHE_RUN_DIR   /var/run/apache2
ENV APACHE_LOCK_DIR  /var/lock/apache2
ENV APACHE_LOG_DIR   /var/log/apache2

RUN mkdir -p $APACHE_RUN_DIR
RUN mkdir -p $APACHE_LOCK_DIR
RUN mkdir -p $APACHE_LOG_DIR
RUN mkdir -p $PATH_WP_MYSITEZ

# Remove the default Server
RUN sed -i '/<Directory \/var\/www\/>/,/<\/Directory>/{/<\/Directory>/ s/.*/# var-www commented/; t; d}' /etc/apache2/apache2.conf

RUN rm /etc/apache2/sites-enabled/000-default.conf

COPY wp_mysitez.conf /etc/apache2/sites-available/

RUN chown --recursive $APACHE_RUN_USER.$APACHE_RUN_GROUP $PATH_WP_MYSITEZ

RUN ln -s /etc/apache2/sites-available/wp_mysitez.conf /etc/apache2/sites-enabled/

# Please note: It would be better to git clone from another location and
# gunzip and delete temporary files in the same line,
# to save space in the layer.
COPY *.sql.gz /tmp/

RUN gunzip /tmp/*.sql.gz; echo "Starting MySQL"; service mysql start && mysql -u root < /tmp/wp_mysitez.sql && mysql -u root < /tmp/mysql.sql; rm -f /tmp/*.sql; rm -f /tmp/*.gz
# After this root will have password assigned

COPY *.zip /tmp/

COPY services_up.sh $PATH_WORDPRESS_SITES

RUN echo "Unzipping..."; cd /var/www/wordpress/; unzip /tmp/*.zip; rm /tmp/*.zip

RUN chown --recursive $APACHE_RUN_USER.$APACHE_RUN_GROUP $PATH_WP_MYSITEZ

EXPOSE 80

CMD ["/var/www/wordpress/services_up.sh"]

Services up

For starting MySQL and Apache I relay in services_up.sh script.

#!/bin/bash
echo "Starting MySql"
service mysql start

echo "Starting Apache"
service apache2 start
# /usr/sbin/apache2 -D FOREGROUND

while [ true ];
do
    ps ax | grep mysql | grep -v "grep "
    if [ $? -gt 0 ];
    then
        service mysql start
    fi
    sleep 10
done

You see that instead of launching apache2 as FOREGROUND, what keeps the loop, not exiting from my Container is a while [ true ]; that will keep looping and checking if MySQL is up, and restarting otherwise.

MySQL shutting down

Some of my sites receive DoS attacks. More than trying to shutdown my sites, are spammers trying to publish comment announcing fake glasses, or medicines for impotence, etc… also some try to hack into the Server to gain control of it with dictionary attacks or trying to explode vulnerabilities.

The downside of those attacks is that some times the Database is under pressure, and uses more and more memory until it crashes.

More memory alleviate the problem and buys time, but I decided not to invest more than $6 USD per month on this old site. I’m just keeping the contents alive and even this site still receives many visits. A restart of the MySQL if it dies is enough for me.

As you have seen in my Dockerfile I only have one Docker Container that runs both Apache and MySQL. One of the advantages of doing like that is that if MySQL dies, the container does not exit. However I could have had two containers with both scripts with the while [ true ];

When planning I decided to have just one single Container, all-in-one, as when I export the image for a Backup, I’ll be dealing only with a single image, not two.

Building and Running the Container

I created a Bash script named build_docker.sh that does the build for me, stopping and cleaning previous Containers:

#!/bin/bash

# Execute with sudo

s_DOCKER_IMAGE_NAME="wp_sitez"

printf "Stopping old image %s\n" "${s_DOCKER_IMAGE_NAME}"
sudo docker stop "${s_DOCKER_IMAGE_NAME}"

printf "Removing old image %s\n" "${s_DOCKER_IMAGE_NAME}"
sudo docker rm "${s_DOCKER_IMAGE_NAME}"

printf "Creating Docker Image %s\n" "${s_DOCKER_IMAGE_NAME}"
# sudo docker build -t ${s_DOCKER_IMAGE_NAME} . --no-cache
sudo docker build -t ${s_DOCKER_IMAGE_NAME} .

i_EXIT_CODE=$?
if [ $i_EXIT_CODE -ne 0 ]; then
    printf "Error. Exit code %s\n" ${i_EXIT_CODE}
    exit
fi

echo "Ready to run ${s_DOCKER_IMAGE_NAME} Docker Container"
echo "To run type: sudo docker run -d -p 80:80 --name ${s_DOCKER_IMAGE_NAME} ${s_DOCKER_IMAGE_NAME}"
echo "or just use run_in_docker.sh"
echo
echo "Debug running Docker:"
echo "docker exec -it ${s_DOCKER_IMAGE_NAME} /bin/bash"
echo

I assign to the image and the Running Container the same name.

Running in Production

Once it works in local, I set the Firewall rules and I deploy the Droplet (VM) with Digital Ocean, I upload the files via SFTP, and then I just run my script build_docker.sh

And assuming everything went well, I run it:

sudo docker run -d -p 80:80 --name wp_mysitez wp_mysitez

I check that the page works, and here we go.

Some improvements

This could also have been put in a private Git repository. You only have to care about not storing the passwords in it. (Like the MySQL grants)

The build from the Git repository can be validated with a Jenkins. Here you have an article about setup a Jenkins for yourself.

News from the blog 2020-09-21

  • I have benchmarked three different CPUs and two Compute optimized Amazon AWS instances with CMIPS 1.0.5 64bit. The two Intel Xeon baremetals equip 2 x Intel Xeon Processor and the third baremetal equips a single Intel Core i7-7800X:

If you’re surprised by the number of cores reported by the Amazon instance m5d.24xlarge, and even more for the baremetal c5n.metal, you’re guessing well that this comes from having Servers with 4 CPUs for Compute Optimized series.

CMIPS ScoreExecution time (seconds)Type of instanceTotal coresCPU model seen by Linux
5853634.16Amazon AWS m5d.24xlarge964 x Intel(R) Xeon(R) Platinum 8175M CPU @ 2.50GHz
5416936.92Amazon AWS c5n.metal724 x Intel(R) Xeon(R) Platinum 8124M CPU @ 3.00GHz
2632975.96Baremetal482 x Intel(R) Xeon(R) CPU E5-2650 v4 @ 2.20GHz
2173292.02Baremetal402 x Intel(R) Xeon(R) CPU E5-2650 v3 @ 2.30GHz
9810203.87Desktop computer12Intel(R) Core(TM) i7-7800X CPU @ 3.50 GHz

  • I can recommend these courses in Linux Academy:

https://linuxacademy.com/cp/library/catalog/view/DevOpsCourses

I’m finishing the 24 hours long Implementing a Full CI/CD Pipeline:

https://linuxacademy.com/cp/modules/view/id/218

  • When I can choose I use Linux, but in many companies I work with Windows workstations. I’ve published a list of useful Software I use in all my Windows workstations.
  • WFH I currently use two external monitors attached to the laptop. I planned to add a new one using a Display Port connected to the Dell USB-C dongle that provides me Ethernet and one additional HDMI as well. I got the cable from Amazon but unfortunately something is not working. In order to make myself comfortable and see some the graphs of the systems worldwide as I have on the office’s displays, I created a small HTML page, that joins several monitor pages in one single web page using frames.
    This way I only have one page loaded on the browser, maximized, and this monitor is dedicated to those graphs of the stats of the Systems.
    Something very simple, but very useful. You can extend the number of columns and rows it to have more graphics in the same screen.
<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Frameset//EN"
   "http://www.w3.org/TR/html4/frameset.dtd">
<HTML>
<HEAD>
<TITLE>Casa Monitor</TITLE>
</HEAD>
<FRAMESET cols="50%,50%">
  <FRAMESET rows="50%,*">
      <FRAME src="http://players-all-games/">
      <FRAME src="http://monthly-graphs/">
  </FRAMESET>
  <FRAMESET rows="50%,*">
	  <FRAME src="http://grafana/databases/">
	  <FRAME src="http://kibana/clusters/">
  </FRAMESET>
</FRAMESET>
</HTML>

If you don’t have the space or the resources for more monitors you can use the ingenious.

I have a cheap HDMI switch that allows me to do PinP (Picture in Picture) with one main source on the monitor, and two using a fraction of their original space. It may allow you to see variants in graphics.

And in you have only a single monitor, you can use a chrome extension that rotates tabs, which is also very useful.

Be careful if you use the reload features with software like Jira or Confluence. If they are slow normally, imagine if you mess it by reloading every 30 seconds… I discourage you to use auto refresh on these kind of Softwares.

My laptop and my Xbox One controller

This past week I have connected the XBOX One X Controller to the Windows laptop for the first time. Normally I use the Pc only for strategy games, but I wanted to play other games like Lost Planet 3, or Fall Guys in a console mode way. I figured that would be very easy and it was. You turn on the controller, press the connect button like you did to pair with the console, and in Windows indicate pair to a Xbox One controller. That’s it.

  • I’ve also updated my Python 3 Combat Guide, to add the explanation, step by step, about how to refactor and make resilient, and add Unit Testing to a spaghetti code, and turn it into a modern OOP. Is currently 255 DIN-A4 pages.
  • This is something I wanted to share with you for a while.
    One of the most funny things in my career is what I call:
    Squirrel Strikes Back

I named this as the first incident where a provider told that the reason of a fiber failure was a squirrel chewing the cable.

I popularized this with my friends in Systems Administration and SRE and when they suffer a Squirrel Attack incident, they forward it to me, for great joy.

I’m used to construction or gas, water, electricity, highways repair operations on the cities accidentally cutting fiber cables, thunders or truck accidents on the highway breaking the floor and cutting tubes and issues like that. I’ve been seeing that for around 25 years.

So the first time I saw a provider referring to a squirrel cutting the cables it was pretty hilarious. :)

In my funny mental picture: I could visually imagine a cable thrown in the middle of the forest, over trees, and a squirrel chewing it as it tastes like peanuts. :) or a shark cutting a Google’s or Facebook’s intercontinental cable thrown without any protection. ;)

The sense of humor and the good vibes, are two of the most important things in life.

How to recover access to your Amazon AWS EC2 instance if you loss your Private Key for SSH

This article covers the desperate situation where you had generated one or more instances, instructed Amazon to use a SSH Key Pair certs where only you have the Private Key, your instances are running, for example, an eCommerce site, running for months, and then you loss your Private Key (.pem file), and with it the SSH access to your instances’ Data.

Actually I’ve seen this situation happening several times, in actual companies. Mainly Start ups. And I solved it for them.

Assuming that you didn’t have a secondary method to access, which is another combination of username/password or other user/KeyPairs, and so you completely lost the access to the Database, the Webservers, etc… I’m going to show you how to recover the data.

For this article I will consider an scenario where there is only one Instance, which contains everything for your eCommerce: Webserver, code, and Database… and is a simple config, with a single persistent drive.

Warning: be very careful as if you use ephemeral drives, contents will be lost is you power off the instance.

Method 1: Quicker, launching a new instance from the previous

Step1: The first step you will take is to close the access from outside, using the Firewall, to avoid any new changes going to the disk. You can allow access to the instance only from your static Ip in the office/home.

Step 2: You’ll wait for 5 minutes to allow any transaction going on to conclude, and pending writes to be flushed to disk.

Step 3: From Amazon AWS Console, EC2, you’ll request an Snapshot. That step is to try to get extra security. Taking an Snapshot from a live, mounted, filesystem, is not the best of ideas, specially of a Database, but we are facing a desperate situation so we’re increasing the numbers of leaving this situation without Data loss. This is just for extra security and if everything goes well at the end you will not need this snapshot.

Make sure you select No reboot.

Step 4: Be very careful if you have extra drives and ephemeral drives.

Step 5: Wait till the Snapshot completes.

Step 6: Then request a graceful poweroff. Amazon will try to poweroff the Server in a gentle way. This may take two minutes.

Step 7: When the instance is powered off, request a new Snapshot. This is the one we really want. The other was just to be more safe. If you feel confident you can just unclick No Reboot on the previous Step and do only one Snapshot.

Step 8: Wait till the Snapshot completes.

Step 9: Generate and upload the new key you will use to AWS Console, or ask Amazon to generate a key pair for you. You can do it while creating the new instance through the wizard.

Step 10: Launch a new instance, based on your snapshot AMI. This will generate a copy of your previous instance (using the Snapshot) for the new one. Select the new Key pair. Finish assigning the Security groups, the elastic ip…

Step 11: Start the new instance. You can select a different flavor, like a more powerful instance, if you prefer. (scale vertically)

Step 12: Test your access by login via SSH with the new pair keys and from your static Ip which has access in the Firewall.

ssh -i /home/carles/Desktop/Data/keys/carles-ecommerce.pem ubuntu@54.208.225.14

Step 13: Check that the web Starts correctly, check the Database logs to see if there is any corruption. Should not have any if graceful shutdown went well.

Step 14: Reopen the access from the Firewall, so the world can connect to your instance.

Method 2: Slower, access the Data and rebuild whatever you need

The second method is exactly the same until Step 6 included.

Step 7: After this, you will create a new instance based on your favorite OS, with a new pair of Keys.

Step 8: You’ll detach the Volume from the eCommerce previous instance (the one you lost access).

Step 9: You’ll attach the Volume to the new instance.

Step 10: You’ll have access to the Data from the previous instance in the new volume. type cat /proc/partitions or df -h to see the mountpoints available. You can then download or backup, or install the Software again and import the Database…

Step 11: Check that everything works, and enable the access worldwide to the Web in the Firewall (Security Group Inbound Rules).

If you are confident enough, you can use this method to upgrade the OS or base Software of your instance, making it part of your maintenance window. For example, to get the last version of Ubuntu or CentOS, MySQL, Python or PHP, etc…
